OVERC.V S-H 3C 3:1
Cartridge Style Counterbalance Valve. Pilot assisted, designed for motion control applications.
Features
- Poppet construction for minimal leakage.
- Incorporates direct acting relief valve for overload protection.
- Includes reverse check valve within body, saving space and minimizing installation cost.
- Excellent control and very good stability.
- Hardened working parts for maximum durability.
- All external parts zinc plated.
Partnumber:
E2B60ZN
Package size:
0 pcs
Min. order quantity is:
1 pcs
Brand Name
Hydraspecma
Cavity
3C
Flow rate nominal LMin
120 lpm
Oil viscocity recommended
15 - 50 cSt
Pilot ratio
3:1
Pressure max.
350 bar
Pressure setting max.
350 bar
Pressure setting min.
50 bar
Sealing material
NBR
Torque tightening
85 Nm
Package size
0 pcs
Barcode
5704295028514
Gross weight
Kg
Net weight
Kg
Country of origin
gbr
Intrastat code
84812010
Cartridge Style Counterbalance Valve. Pilot assisted, designed for motion control applications.
Features
- Poppet construction for minimal leakage.
- Incorporates direct acting relief valve for overload protection.
- Includes reverse check valve within body, saving space and minimizing installation cost.
- Excellent control and very good stability.
- Hardened working parts for maximum durability.
- All external parts zinc plated.
