Plus+1 Prop.v. 2/1 NO 30l/m PFC10-RO-30-00-00-B-00

Partnumber:

850255019

Package size:

0 pcs

Min. order quantity is:

1 pcs

Accessories (10)

Mix-N-Match Dual Cross Body 1/2"DCP10-2-4B

Partnumber: 11135684

Mix-N-Match Dual Parallel Body 1/2"DPL10-2-4B

Partnumber: 11137221

Housing SDC10-2-S3B steel 3/8

Partnumber: 11143048

Housing SDC10-2-S4B steel 1/2 port

Partnumber: 11143049

Coil M19P-12D-1.8A-DN

Partnumber: 171132519

COIL, M19P-24D-0.9A-DN M19P-24D-0.9A-DN

Partnumber: 171132619

Coil M19P-12D-1.8A-DE

Partnumber: 171147519

Coil M19P-24D-0.9A-DE

Partnumber: 171147619

HOUSING, SDC10-2-DG3B (3/8) SDC10-2-DG3B (3/8)

Partnumber: 922516910

HOUSING, SDC10-2-DG4B (1/2) SDC10-2-DG4B (1/2)

Partnumber: 922517010

Specifications
Dimensions and shipping

Activation

Manual override, Solenoid proportional

Brand Name

Danfoss

Cavity

SDC10-2

Contamination level max.

18/17/13 - ISO 4406

Current type

Filter built-in

Flow rate nominal LMin

30 lpm

Model code

PFC10-RO-30-00-00-B-00

Number of ways/positions

2/2

Oil viscocity recommended

12 - 54 cSt

Pressure max.

260 bar

Solenoidtype

M19P

Temperature max.

+100 °C

Temperature min.

-40 °C

Torque tightening

122 - 136 Nm

Valve type

Flow control, pressure compensated

Package size

0 pcs

Barcode

5704334466338

Gross weight

0,88 Kg

Net weight

0,88 Kg

Country of origin

Intrastat code

84812010

Product information

Plus+1 Prop.v. 2/1 NO 30l/m PFC10-RO-30-00-00-B-00

Product datasheet
